BT-ETA / BT-OME

● MAS403 / BT EXT Standard Holder
▶ BT-ETA

Code No. 치수 Dimension(mm) 부품 Component
BT30-ETA-22045
BT30-ETA-28055 D dL MB
BT40-ETA-22055 40 22 45
BT40-ETA-28055 50 28 55 M12 MTB-10145
BT40-ETA-36055 40 22 55 MTB-12175
BT50-ETA-22065 50 28 55 MTB-10145
BT50-ETA-28070 63 36 55 M16 MTB-12175
BT50-ETA-36080 40 22 65 MTB-16225
BT50-ETA-45080 50 28 70 MTB-10145
BT50-ETA-55080 63 36 80 MTB-12175
80 45 80 M24 MTB-16225
TOOL HOLDER 100 55 80 MTB-16260
MTB-20330

● MAS403 / BT EXT Modular Oil Feed Type
▶ BT-OME

Code No. 치수 Dimension(mm) 부품 Component

dL D D1 M B

BT40-OME-22090 22 90 50 78 MTB-10145
BT40-OME-28095 28 95 50 78 M16 MTB-12175
BT40-OME-36100 36 100 65 98
BT50-OME-22105 22 105 50 78 MTB-16225
MTB-10145
BT50-OME-28105 28 105 50 78 MTB-12175
BT50-OME-36120 36 120 65 98 M24 MTB-16225

BT50-OME-45120 45 120 80 115 MTB-16260

※ 수동 내부 급유형 절삭유 공급 홀더로, 특수 씰을 장착하여 누유없이 장시간 운전이 가능합니다. (Max. 1800RPM/138페이지참조)
※ It is a manual type internal oil hole holder with a special seal capable of long term operation without leakage.

(Max. 1800RPM/refer to page 138)
