SK-ETA / SK-OME

● DIN69871 / SK EXT Standard Type
▶ SK-ETA

Code No. 치수 Dimension(mm) 부품 Component
SK40-ETA-22045
SK40-ETA-28050 D d LM B
SK40-ETA-36065 40
SK50-ETA-22045 50 22 45 MTB-10145
SK50-ETA-28050 63 28 50 M16 MTB-12175
SK50-ETA-36060 40 36 65 MTB-16225
SK50-ETA-45060 50 22 45
63 28 50 MTB-10145
80 36 60 MTB-12175
M24 MTB-16225

45 60 MTB-16260

TOOL HOLDER

● DIN69871 / SK EXT Modular Oil Feed Type
▶ SK-OME

Code No. 치수 Dimension(mm) 부품 Component
SK40-OME-22095
SK40-OME-28100 d LD D1 M B
SK40-OME-36105 22 95 50 78 M16 MTB-10145
SK50-OME-22090 28 100 50 78 MTB-12175
SK50-OME-28105 36 105 65 98 M24 MTB-16225
SK50-OME-36105 22 90 50 78 MTB-10145
SK50-OME-45105 28 105 50 78 MTB-12175
36 105 65 98 MTB-16225
45 105 80 115 MTB-16260

※ 수동 내부 급유형 절삭유 공급 홀더로, 특수 씰을 장착하여 누유없이 장시간 운전이 가능합니다. (Max. 1800RPM/138페이지참조)
※ It is a manual type internal oil hole holder with a special seal capable of long term operation without leakage.

(Max. 1800RPM/refer to page 138)
