KSD 3×D

DRILLING

● Shank ISO9766, Parallel with clamping flat

Code No. 치수 Dimension(mm) 인서트 Insert 부품 Component
KSD-2403D-S32 내측 외측 Screw T-Driver
KSD-2453D-S32 D L1 L Ds Ls
KSD-2503D-S32 60
KSD-2553D-S32 24.0 75 165
KSD-2603D-S32 24.5 77 167 70
KSD-2653D-S32 25.0 78 168
KSD-2703D-S32 25.5 80 170
KSD-2753D-S32 26.0 81 171
KSD-2803D-S32 26.5 83 173
KSD-2853D-S32 27.0 84 174 XOMT090305 PD SPMT090308 PD TSB-30072 TXL-8
KSD-2903D-S32
KSD-2953D-S32 27.5 86 176
KSD-3003D-S32 28.0 87 177
KSD-3103D-S32 28.5 89 179 32
KSD-3203D-S32
KSD-3303D-S32 29.0 90 180
KSD-3403D-S32 29.5 92 182
KSD-3503D-S32 30.0 95 185
KSD-3603D-S40 31.0 98 188
KSD-3703D-S40 32.0 101 191
KSD-3803D-S40 33.0 104 194 XOMT11T306 PD SPMT11T308 PD TSB-35080
KSD-3903D-S40 34.0 107 197 TXL-15
KSD-4003D-S40 35.0 110 200
KSD-4103D-S40 36.0 113 218 XOMT130406 PD SPMT130410 PD TSB-40100
KSD-4203D-S40 37.0 116 221
KSD-4303D-S40 38.0 119 224 XOMT15M508 PD SPMT15M510 PD
KSD-4403D-S40 39.0 122 227
KSD-4503D-S40 40.0 125 230 TSB-50125 TXL-20
KSD-4603D-S40 41.0 128 233 XOMT180508 PD SPMT180510 PD
KSD-4703D-S40 42.0 131 236
KSD-4803D-S40 43.0 134 239
KSD-4903D-S40 44.0 137 242
KSD-5003D-S40 45.0 140 245
KSD-5103D-S40 46.0 143 248
KSD-5203D-S40 47.0 146 251
KSD-5303D-S40 48.0 149 254 40
KSD-5403D-S40 49.0 152 257
KSD-5503D-S40 50.0 155 260
KSD-5603D-S40 51.0 158 263
KSD-5703D-S40 52.0 161 266
KSD-5803D-S40 53.0 164 269
KSD-5903D-S40 54.0 167 272
KSD-6003D-S40 55.0 170 275
56.0 173 278
57.0 176 281
58.0 179 284
59.0 182 287
60.0 185 290

※ 범용선반 작업할 경우, 가공직경 ø40 이상이면 VLT나, VMD 사용을 권장합니다.
KSD와 체결되는 툴 홀더는 '사이드락 아버'(78페이지~90페이지)입니다.

※ If you are working on the lathe, diameter ø40 or higher, we recommend using the VLT, VMD
The tool holder that locks with KSD is Side Lock Arbor.(p.78~p.90)
