KSD 3×D

DRILLING

● Shank ISO9766, Parallel with clamping flat

Code No. 치수 Dimension(mm) 인서트 Insert 부품 Component
KSD-1303D-S20 내측 외측 Screw T-Driver
KSD-1353D-S20 D L1 L Ds Ls XOMT040204 PD SPMT040204 PD
KSD-1403D-S20 50
KSD-1453D-S20 13.0 42 112
KSD-1503D-S20 13.5 44 114 56
KSD-1553D-S20 14.0 45 115
KSD-1603D-S20 14.5 47 117 20 TSB-20045
KSD-1653D-S25 15.0 48 118 XOMT050204 PD SPMT050204 PD
KSD-1703D-S25 15.5 50 120
KSD-1753D-S25 16.0 51 121
KSD-1803D-S25 16.5 53 134 TXL-6
KSD-1853D-S25
KSD-1903D-S25 17.0 54 135 XOMT060204 PD SPMT060205 PD TSB-22052
KSD-1953D-S25 17.5 56 137
KSD-2003D-S25 18.0 57 138
KSD-2053D-S25 18.5 59 140
KSD-2103D-S25 19.0 60 141
KSD-2153D-S25 19.5 62 143
KSD-2203D-S25 20.0 63 144 25
KSD-2253D-S25 20.5 65 146
KSD-2303D-S25 21.0 66 147
KSD-2353D-S25 21.5 68 149
22.0 69 150 XOMT07T205 PD SPMT07T208 PD TSB-25065 TXL-8
22.5 71 152
23.0 72 153
23.5 74 155

※ 최고의 결과물을 위해서는 절삭조건표(123페이지)와 절삭유 적정 압력을 확인해 주세요.(절삭유 적정압력은 5kg/㎠ 이상입니다.)
※ Please make sure the proper oil pressure and the cutting date(P.123)for the best performance.(The proper pressure is over 5kg/㎠)

● KSD 드릴 홀 공차 Hole tolerance of KSD drill

Diameter 2×D 3×D 4×D
ø13 ~ø23.5 -0.10 ~ +0.15 -0.10 ~ +0.18 -0.12 ~ +0.20
ø30 ~ø42 -0.10 ~ +0.15 -0.12 ~ +0.22 -0.12 ~ +0.25
ø43 ~ø60 -0.10 ~ +0.20 -0.12 ~ +0.25 -0.15 ~ +0.27

※ 홀 공차는 드릴의 길이, 피삭재, 장비, 가공조건 등에 따라 차이가 생길 수 있습니다.
※ The length of drill, kind of workpiece, machine stability, and cutting condition could affect the hole tolerance.
