KSD 2×D

DRILLING

● Shank ISO9766, Parallel with clamping flat

Code No. 치수 Dimension(mm) 인서트 Insert 부품 Component
KSD-2402D-S32 내측 외측 Screw T-Driver
KSD-2452D-S32 D L1 L Ds Ls
KSD-2502D-S32 60
KSD-2552D-S32 24.0 51 141 XOMT090305 PD SPMT090308 PD TSB-30072 TXL-8
KSD-2602D-S32 24.5 52 142 70
KSD-2652D-S32 25.0 53 143 32 XOMT11T306 PD SPMT11T308 PD TSB-35080
KSD-2702D-S32 25.5 54 144 40 TXL-15
KSD-2752D-S32 26.0 55 145
KSD-2802D-S32 26.5 56 146 XOMT130406 PD SPMT130410 PD TSB-40100
KSD-2852D-S32 27.0 57 147
KSD-2902D-S32 27.5 58 148 XOMT15M508 PD SPMT15M510 PD
KSD-2952D-S32 28.0 59 149
KSD-3002D-S32 28.5 60 150 TSB-50125 TXL-20
KSD-3102D-S32 29.0 61 151 XOMT180508 PD SPMT180510 PD
KSD-3202D-S32 29.5 62 152
KSD-3302D-S32 30.0 65 155
KSD-3402D-S32 31.0 67 157
KSD-3502D-S32 32.0 69 159
KSD-3602D-S40 33.0 71 161
KSD-3702D-S40 34.0 73 163
KSD-3802D-S40 35.0 75 165
KSD-3902D-S40 36.0 77 182
KSD-4002D-S40 37.0 79 184
KSD-4102D-S40 38.0 81 186
KSD-4202D-S40 39.0 83 188
KSD-4302D-S40 40.0 85 190
KSD-4402D-S40 41.0 87 192
KSD-4502D-S40 42.0 89 194
KSD-4602D-S40 43.0 91 196
KSD-4702D-S40 44.0 93 198
KSD-4802D-S40 45.0 95 200
KSD-4902D-S40 46.0 97 202
KSD-5002D-S40 47.0 99 204
KSD-5102D-S40 48.0 101 206
KSD-5202D-S40 49.0 103 208
KSD-5302D-S40 50.0 105 210
KSD-5402D-S40 51.0 107 212
KSD-5502D-S40 52.0 109 214
KSD-5602D-S40 53.0 111 216
KSD-5702D-S40 54.0 113 218
KSD-5802D-S40 55.0 115 220
KSD-5902D-S40 56.0 117 222
KSD-6002D-S40 57.0 119 224
58.0 121 226
59.0 123 228
60.0 125 230

※ 범용선반 작업할 경우, 가공직경 ø40 이상이면 VLT나, VMD 사용을 권장합니다.
KSD와 체결되는 툴 홀더는 '사이드락 아버'(78페이지~90페이지)입니다.

※ If you are working on the lathe, diameter ø40 or higher, we recommend using the VLT, VMD
The tool holder that locks with KSD is Side Lock Arbor.(p.78~p.90)
