KSD 4×D

DRILLING

● Shank ISO9766, Parallel with clamping flat

Code No. 치수 Dimension(mm) 인서트 Insert 부품 Component
KSD-2404D-S32 내측 외측 Screw T-Driver
KSD-2454D-S32 D L1 L Ds Ls
KSD-2504D-S32 60
KSD-2554D-S32 24.0 99 189
KSD-2604D-S32 24.5 101 191 70
KSD-2654D-S32 25.0 103 193
KSD-2704D-S32 25.5 105 195
KSD-2754D-S32 26.0 107 197
KSD-2804D-S32 26.5 109 199
KSD-2854D-S32 27.0 111 201 XOMT090305 PD SPMT090308 PD TSB-30072 TXL-8
KSD-2904D-S32
KSD-2954D-S32 27.5 113 203
KSD-3004D-S32 28.0 115 205
KSD-3104D-S32 28.5 117 207 32
KSD-3204D-S32
KSD-3304D-S32 29.0 119 209
KSD-3404D-S32 29.5 121 211
KSD-3504D-S32 30.0 125 215
KSD-3604D-S40 31.0 129 219
KSD-3704D-S40 32.0 133 223
KSD-3804D-S40 33.0 137 227 XOMT11T306 PD SPMT11T308 PD TSB-35080
KSD-3904D-S40 34.0 141 231 TXL-15
KSD-4004D-S40 35.0 145 235
KSD-4104D-S40 36.0 149 254 XOMT130406 PD SPMT130410 PD TSB-40100
KSD-4204D-S40 37.0 153 258
KSD-4304D-S40 38.0 157 262 XOMT15M508 PD SPMT15M510 PD
KSD-4404D-S40 39.0 161 266
KSD-4504D-S40 40.0 165 270 TSB-50125 TXL-20
KSD-4604D-S40 41.0 169 274 XOMT180508 PD SPMT180510 PD
KSD-4704D-S40 42.0 173 278
KSD-4804D-S40 43.0 177 282
KSD-4904D-S40 44.0 181 286
KSD-5004D-S40 45.0 185 290
KSD-5104D-S40 46.0 189 294
KSD-5204D-S40 47.0 193 298
KSD-5304D-S40 48.0 197 302 40
KSD-5404D-S40 49.0 201 306
KSD-5504D-S40 50.0 205 310
KSD-5604D-S40 51.0 209 314
KSD-5704D-S40 52.0 213 318
KSD-5804D-S40 53.0 217 322
KSD-5904D-S40 54.0 221 326
KSD-6004D-S40 55.0 225 330
56.0 229 334
57.0 233 338
58.0 237 342
59.0 241 346
60.0 245 350

※ 범용선반 작업할 경우, 가공직경 ø40 이상이면 VLT나, VMD 사용을 권장합니다.
KSD와 체결되는 툴 홀더는 '사이드락 아버'(78페이지~90페이지)입니다.

※ If you are working on the lathe, diameter ø40 or higher, we recommend using the VLT, VMD
The tool holder that locks with KSD is Side Lock Arbor.(P.78~P.90)
