VLT 5×D

DRILLING D
DS

L1 LS
L

● Shank ISO9766, Parallel with clamping flat

▶ STANDARD TYPE

Code No. 치수 Dimension(mm) 센터드릴 인서트 부품 Component
D L1 L Ds Ls Pilot Drill Insert Screw Driver
PLD-V0630
VLT-25050D S32 25 WCMX030204 TSB-22045 TXL-6
VLT-26050D S32 26 TiN
VLT-27050D S32 27
VLT-28050D S32 28 150 240 PLD-V0835 WCMX040204 TSB-25055
VLT-29050D S32 TiN
VLT-30050D S32 29
VLT-31050D S32 30
VLT-32050D S32 31
VLT-33050D S32 32
VLT-34050D S32 33 175 265 32 60
VLT-35050D S32
VLT-36050D S32 34 TXL-8
VLT-37050D S32 35 WCMX050308 TSB-30070
VLT-38050D S32 36
VLT-39050D S32 37
VLT-40050D S32 38 200 290
39
40

※ ø25~ø40 : 일반형 Standard Type

● Shank ISO9766, Parallel with clamping flat Shank Ds Ls
▶ SINGLE INSERT CARTRIDGE TYPE S40 40 70

Code No. 치수 Dimension(mm) 센터드릴 인서트 부품 Component 카트리지 Cartridge
D L1 L Pilot Drill Insert Screw Driver
Inner Outer
41 VLC- VLC-000410T
42 410450N VLC-000420T
VLT-414550D S40 43 225 330 VLC- VLC-000430T
VLT-465050D S40 44 460500N VLC-000440T
VLT-515550D S40 45 WCMX TSB- VLC-000450T
VLT-565950D S40 46 PLD-V1035 06T308 35078 VLC- VLC-000460T
47 510550N VLC-000470T
TiN-H VLC-000480T
VLC- VLC-000490T
48 250 355 560590N VLC-000500T
49 VLC-000510T
50 TXL-15 VLC-000520T
VLC-000530T
51 VLC-000540T
52 VLC-000550T
53 275 380 VLC-000560T
54 VLC-000570T
55 PLD-V1238 WCMX TSB- VLC-000580T
56 TiN-H 080408 40110 VLC-000590T

57 300 405
58
59

※ ø41~ø59 : 1mm단위 개별 카트리지 사용으로 직경을 조절합니다.
※ ø41~ø59 : Adjustable 5mm unit when you replace individual outer cartridge(1mm)
