FXD 6×D
DRILLING
● Shank ISO9766, Parallel with clamping flat
Code No. 치수 Dimension(mm) B 인서트 Insert Torx 센터드릴
D L1 L Ds Ls Insert Screw Screw Pilot Drill
FXD-18060D S25 18.0 112 198 SPMX TSB-
FXD-18560D S25 18.5 115 201 050204 20045
FXD-19060D S25 19.0 118 204
FXD-19560D S25 19.5 121 207 25 56 PT-1/8 TXL-6 PLD-0620
FXD-20060D S25 20.0 124 210 32 TiN
FXD-20560D S25 20.5 127 213 SPMX TSB-
FXD-21060D S25 21.0 130 216 060204 22052
FXD-21560D S25 21.5 133 219
FXD-22060D S25 22.0 136 222 60 PT-1/4 SPMX TSB- TXL-8 PLD-0825
FXD-22560D S25 22.5 139 225 07T308 25065 TiN
FXD-23060D S25 23.0 142 228
FXD-23560D S25 23.5 145 231
FXD-24060D S25 24.0 148 234
FXD-24560D S25 24.5 151 237
FXD-25060D S25 25.0 154 240
FXD-25560D S32
FXD-26060D S32 25.5 157 252
FXD-26560D S32 26.0 160 255
FXD-27060D S32 26.5 163 258
FXD-27560D S32 27.0 166 261
FXD-28060D S32 27.5 169 264
FXD-28560D S32 28.0 172 267
FXD-29060D S32 28.5 175 270
FXD-29560D S32 29.0 178 273
FXD-30060D S32 29.5 181 276
30.0 184 279
※ FXD DRILL은 겹판가공이 가능합니다. 관통작업시 이송을 30~50%정도 줄여서 작업해주세요.
※ SPMX 인서트는 108페이지를 참조해주세요
※ FXD DRILL is capable of working laminated boards. Please reduce the feed rate by 30%~50% when performing penetration work.
※ Please refer to the page108 regarding SPMX insert.
