DRILLING  Construction System of TURBO DRILL′s Code No.

          ▶ Standard Type

                   FXD - 27540D S32

          드릴종류                                               기공깊이:가공직경의 4배
          Drill group                                        Drilling depth:Dia×4

                                    가공직경:Φ27.5                             생크직경 : Φ32
                                    Drilling diameter:Φ27.5                Shank diameter:Φ32

          ▶ Adjustment Type

                   VLT - 758065D S40

          드릴종류                                               기공깊이:가공직경의 6.5배
          Drill group                                        Drilling depth:Dia×6.5

                                    가공직경:Φ75~Φ80(조절타입)                             생크직경 : Φ40
                                    Drilling diameter:Φ75~Φ80(Adjustable)          Shank diameter:Φ40
