P. 41
MCD 2.5×D
DRILLING
● EXT Modular Shank Type
Code No. 치수 Dimension(mm) 인서트 부품 Component
MCD-13025D Insert
MCD-14025D D L1 L D1 Ds WCMX03T104 Screw Driver
MCD-15025D WCMX030204
MCD-16025D 13 37 89 WCMX040204
MCD-17025D 14 40 92 WCMX050308 TSB-18045
MCD-18025D 15 42 94
MCD-19025D 16 45 97 WCMX06T308
MCD-20025D 17 47 99 TXL-6
MCD-21025D WCMX080408
MCD-22025D 18 50 102 TSB-22045
MCD-23025D 19 52 104
MCD-24025D 20 55 107 40 22
MCD-25025D 28
MCD-26025D 21 58 109 36
MCD-27025D 22 60 112
MCD-28025D 23 63 115 TSB-25055
MCD-29025D 24 65 117 TSB-30070
MCD-30025D 25 68 119
MCD-31025D 26 70 131 TXL-8
MCD-32025D
MCD-33025D 27 73 133
MCD-34025D 28 75 136
MCD-35025D 29 78 138
MCD-36025D 30 80 141
MCD-37025D 31 83 143
MCD-38025D 32 85 146
MCD-39025D 33 88 148
MCD-40025D 34 90 151 50
MCD-41025D
MCD-42025D 35 93 153 TSB-35090
MCD-43025D 36 95 156 TXL-15
MCD-44025D 37 98 158
MCD-45025D 38 100 161 TSB-40110
MCD-46025D 39 103 163
MCD-47025D 40 105 166
MCD-48025D 41 108 168
MCD-49025D 42 110 180
MCD-50025D 43 113 183
MCD-51025D 44 115 185
MCD-52025D 45 118 188
MCD-53025D 46 120 190
MCD-54025D 47 123 193
MCD-55025D 48 125 195
MCD-56025D 49 128 198
MCD-57025D 50 130 200 63
MCD-58025D 51 133 203
52 135 205
53 138 208
54 140 210
55 143 213
56 145 215
57 148 218
58 150 220
※ 가공경 ø40 이상을 범용선반에서 가공할 경우 센터붙이 타입 드릴(TMD, VMD) 사용을 권장합니다.
MCD드릴과 체결되는 툴 홀더는 'EXT 모듈러 툴홀더'(98페이지~102페이지)입니다.
※ If you are working on the lathe, diameter ø40 or higher, we recommend using the TMD, VMD
The tool holder that locks with MCD is EXT Modular Tool holder.(P.98~P.102)
