MCD 2×D
DRILLING
● EXT Modular Shank Type
Code No. 치수 Dimension(mm) 인서트 부품 Component
MCD-13020D Insert
MCD-14020D D L1 L D1 Ds WCMX03T104 Screw Driver
MCD-15020D WCMX030204
MCD-16020D 13 31 83 WCMX040204
MCD-17020D 14 33 85 WCMX050308 TSB-18045
MCD-18020D 15 35 87
MCD-19020D 16 37 89 WCMX06T308
MCD-20020D 17 39 91 TXL-6
MCD-21020D WCMX080408
MCD-22020D 18 41 93 TSB-22045
MCD-23020D 19 43 95
MCD-24020D 20 45 97 40 22
MCD-25020D 28
MCD-26020D 21 47 99 36
MCD-27020D 22 49 101
MCD-28020D 23 51 103 TSB-25055
MCD-29020D 24 53 105 TSB-30070
MCD-30020D 25 55 107
MCD-31020D 26 57 117 TXL-8
MCD-32020D
MCD-33020D 27 59 119
MCD-34020D 28 61 121
MCD-35020D 29 63 123
MCD-36020D 30 65 125
MCD-37020D 31 67 127
MCD-38020D 32 69 129
MCD-39020D 33 71 131
MCD-40020D 34 73 133 50
MCD-41020D
MCD-42020D 35 75 135 TSB-35090
MCD-43020D 36 77 137 TXL-15
MCD-44020D 37 79 139
MCD-45020D 38 81 141 TSB-40110
MCD-46020D 39 83 143
MCD-47020D 40 85 145
MCD-48020D 41 87 147
MCD-49020D 42 89 159
MCD-50020D 43 91 161
MCD-51020D 44 93 163
MCD-52020D 45 95 165
MCD-53020D 46 97 167
MCD-54020D 47 99 169
MCD-55020D 48 101 171
MCD-56020D 49 103 173
MCD-57020D 50 105 175 63
MCD-58020D 51 107 177
52 109 179
53 111 181
54 113 183
55 115 185
56 117 187
57 119 189
58 121 191
※ 가공경 ø40 이상을 범용선반에서 가공할 경우 센터붙이 타입 드릴(TMD, VMD) 사용을 권장합니다.
MCD드릴과 체결되는 툴 홀더는 'EXT 모듈러 툴홀더'(98페이지~102페이지)입니다.
※ If you are working on the lathe, diameter ø40 or higher, we recommend using the TMD, VMD
The tool holder that locks with MCD is EXT Modular Tool holder.(P.98~P.102)
