ER CHUCK (Slim Collet Chuck) ER Shrink Fit
Holder

H Milling
Chuck

D SK Slim
Chuck

TAPER No. NUT ER Collet
L Chuck

DIN 69893/ISO12164-1 HSK FORM A DIN 69893 Taper G Value RPM Coolant N&COHDtroilhlledreCrThsouoclk
- HSK Accuracy 6.3 15,000 System

AT3 -

Unit : mm Morse Taper

TAPER No. MODEL No. CLAMPING RANGE L D H NUT / COLLET 중량(Kg) 재고 Arbor
50A HSK50A-ER11M-75 0.5 - 7.0 75
63A HSK50A-ER16M-85 0.5 - 10.0 85 16 29.5 XSQ-R11M / ER11 0.30
100A HSK50A-ER20M-90 0.5 - 13.0 90
HSK50A-ER25M-105 1.0 - 16.0 105 22 38 XSQ-R16M / ER16 0.40
HSK63A-ER11M-75 0.5 - 7.0 75
HSK63A-ER16M-85 0.5 - 10.0 85 28 44.5 XSQ-R20M / ER20 0.80
HSK63A-ER20M-95 0.5 - 13.0 95
HSK63A-ER25M-105 1.0 - 16.0 105 35 52 XSQ-R25M / ER25 1.20 Synchro Tapping Chuck
HSK100A-ER11M-85 0.5 - 7.0 85
HSK100A-ER16M-95 0.5 - 10.0 95 16 29.5 XSQ-R11M / ER11 0.80
HSK100A-ER20M-100 0.5 - 13.0 100
HSK100A-ER25M-120 1.0 - 16.0 120 22 38 XSQ-R16M / ER16 1.00

28 44.5 XSQ-R20M / ER20 1.20

35 52 XSQ-R25M / ER25 1.40 Tapping ER
Chuck
16 29.5 XSQ-R11M / ER11 2.40

22 38 XSQ-R16M / ER16 2.70

28 44.5 XSQ-R20M / ER20 3.00

35 52 XSQ-R25M / ER25 3.20

▶ ER Collet 적용범위 111-114page 참고 Tapping
▶ ER Nut, Sealing disk, Spanner 적용범위 115-121page 참고 Chuck

Side Lock Arbor
& End Mill Holder

Face Mill
Arbor

Shell Mill
Arbor

Boring
System
