CUTTER SERIES5
BALL CUTTER FINISHING

▶ BFCC

- STRIGHT SHANK TYPE INSERT TYPE → WIDIN, WALTER

Part No. R 치수(Dimensions)mm L1
6 Dd L
BFCC-R0612150 6 12 12 150 35 P3204-D120 FS-391 TX-15
BFCC-R0612180 8 FS-392 TX-15
BFCC-R0816160 8 12 12 180 35 SP3204-D120 FS-393 TX-20
BFCC-R0816200 10 16 16 160 FS-394 TX-20
BFCC-R1020200 10 16 16 200 50 P3204-D150
BFCC-R1020250 12.5 20 20 200 FS-395 TX-30
BFCC-R1225200 12.5 20 20 250 50 SP3204-D150
BFCC-R1225250 15 25 25 200
BFCC-R1532200 15 25 25 250 70 P3204-D200
BFCC-R1532250 15 30 32 200
BFCC-R1532300 30 32 250 70 SP3204-D200
30 32 300
80 P3204-D250

80 SP3204-D250

100 P3204-D300
100 SP3204-D300
100

▶ C-BFCC

- CARBIDE SHANK TYPE INSERT TYPE → WIDIN, WALTER

Part No. 치수(Dimensions)mm L1
RDd L

C-BFCC-R0510150 5 10 10 150 25 P3204-D100 FS-90
FS-391
C-BFCC-R0612165 6 12 12 165 35 P3204-0120 FS-392
FS-393
커터 시리즈 C-BFCC-R0612200 6 12 12 200 35 SP3204-D120 TX-15
FS-394
C-BFCC-R0816200 8 16 16 200 50 P3204-D160 TX-20
FS-395 TX-30
C-BFCC-R0816250 8 16 16 250 50 SP3204-D160

C-BFCC-R1020220 10 20 20 220 70 P3204-D200

C-BFCC-R1020300 10 20 20 300 70 SP3204-D200

C-BFCC-R1225200 12.5 25 25 200 80 P3204-D250
80 SP3204-D250
C-BFCC-R1225250 12.5 25 25 250 80

C-BFCC-R1225300 12.5 25 25 300

C-BFCC-R1532250 15 30 32 250 100 P3204-D300

C-BFCC-R1532300 15 30 32 300 100 SP3204-D300
