BALL CUTTER 5

▶ M-BFCC CUTTER SERIES

- MODULAR SHANK TYPE INSERT TYPE → WIDIN, WALTER

Part No. 치수(Dimensions)mm
M-BFCC-R08xM8
R D d L L1 I M E

8 16 8.5 45 28 6 8 12 SP3204..D16 TSB-392 TX-15

M-BFCC-R10xM10 10 20 10.5 52 33 6 10 15 SP3204..D20 TSB-393 TX-25

M-BFCC-R12.5xM12 12.5 25 12.5 60 38 6 12 19 SP3204..D25 TSB-394 TX-25

M-BFCC-R15xM16 15 30 17 68 45 6 16 22 SP3204..D30 TSB-395 TX-30

▶ M-SRM

- MODULAR SHANK TYPE INSERT TYPE → MITSUBISHI

Part No. 치수(Dimensions)mm 안날 바깥날 NO.OF ST2553-55 M2.5 TX-8
M-SRM-R08xM8 R D d L L1 I M E INSERT ST3072-60H M3 TX-8
8 16 8.5 45 28 6 8 12 SR.16C SR.16E ST4104-60W M4 TX-15
15 SR.20C SR.20E 2 ST511-60H M5 TX-20
M-SRM-R10xM10 10 20 10.5 52 33 6 10 19 SR.25C SR.25E 커터 시리즈
22 SR.30C SR.30E
M-SRM-R12.5xM12 12.5 25 12.5 60 38 6 12

M-SRM-R15xM16 15 30 17 68 45 6 12
