CUTTER SERIES5
ENDMILL CUTTER

▶ M-ASRL

E

M
Dd

R l
L1

L

- MODULAR SHANK TYPE INSERT TYPE → HITACHI, WIDIN

Part No. 치수(Dimensions)mm ER
D d L L1 I M 15 10
15 10
M-ASRL-D20xM10 20 10.5 52 33 6 10 19 10 ED.W ST509-55
19 10 0803TN-10 M3.5
M-ASRL-D21xM10 21 10.5 52 33 6 10 24 15(10) TX-15
24 15(10) ED.W ST408-43 TX-20
M-ASRL-D25xM12 25 12.5 60 38 6 12 2 10T3TN-10 CL2C M4
2CLCN
M-ASRL-D26xM12 26 12.5 60 38 6 12 ED.W ST512-63P
13T4TN-15(10) 3CLCN M4
M-ASRL-D32xM16 32 17 68 45 6 12

M-ASRL-D33xM16 33 17 68 45 6 16

▶ M-ASRL-Pico

E
M
Dd

L1 l
L

- MODULAR SHANK TYPE INSERT TYPE → HITACHI, WIDIN

커터 시리즈 Part No. 치수(Dimensions)mm E 2
M-ASRL-D16xM8 D d L L1 I M 12 2
16 8.5 45 28 6 8 12 3
15 3
M-ASRL-D17xM8 17 8.5 45 28 6 8 15 4
19 4
M-ASRL-D20xM10 20 10.5 52 33 6 10 19 5
24 5
M-ASRL-D21xM10 21 10.5 52 33 6 10 24 6 ST2553-55
24 M2.5
M-ASRL-D25xM12 25 12.5 60 38 6 12 EPMW0603 TX-8

M-ASRL-D26xM12 26 12.5 60 38 6 12

M-ASRL-D32xM16 32 17 68 45 6 12

M-ASRL-D33xM16 33 17 68 45 6 16

M-ASRL-D40xM16 40 17 68 45 6 16

718
