INSERT TIP 5

▶ 정삭 볼 인서트 / Finishing Ball Insert CUTTER SERIES

- 적용 HOLDER : ABPF(701p), C-ABPF(701p), M-ABPF(714p) INSERT TYPE → WIDIN

Part No. R 치수(Dimensions)mm T
6 DL 3.2
ZPSW 120 6.5 12 14.5 3.2
ZPSW 130 8 13 14.5 4.2
ZPSW 160 8.5 16 16.5 4.2
ZPSW 170 10 17 16.5 5.2
ZPSW 200 10.5 20 20.5 5.2
ZPSW 210 12.5 21 20.5 6.2
ZPSW 250 13 25 24.0 6.2
ZPSW 260 15 26 24.0 7.2
ZPSW 300 16 30 29.0 7.2
ZPSW 320 32 30.0

- 적용 HOLDER : BFCC(700p), M-BFCC(714p) INSERT TYPE → WIDIN

Part No. D 치수(Dimensions)mm S 커터 시리즈
10 D1 L 2.5
SP3204-D100 12 45 2.5
SP3204-D120 16 56 3
SP3204-D160 20 56 3
SP3204-D200 25 56 4
SP3204-D250 30 69 5
SP3204-D300 32 8 10 5
SP3204-D320 8 10
