INSERT TIP 5

▶ 라운드 인서트 / Round Insert CUTTER SERIES

°

- 적용 HOLDER : C-RDT(684p) D T

Part No. D 치수(Dimensions)mm INSERT TYPE → WIDIN
5.0 TQ 재질
RDMW0501 7.0 1.4 15˚
RDMW0702 10.0 2.38 15˚
RDMW1003 3.18 15˚

▶ 볼 인서트 / Ball Insert(Indexable Milling)

R

IT 커터 시리즈

- 적용 HOLDER : SRFH(702p), C-SRFH(702p), M-SRFH(714p) INSERT TYPE → WIDIN d

Part No. I 치수(Dimensions)mm R
dT 4
4.5
LBH - 080 7.0 8.0 2.4 5
5.5
LBH - 090 7.5 9.0 2.4 6
6.5
LBH - 100 8.5 10.0 2.6 8
8.5
LBH - 110 9.0 11.0 2.6 10
10.5
LBH - 120 10.0 12.0 3 12.5
13
LBH - 130 10.5 13.0 3 15
15.5
LBH - 160 12.0 16.0 4 16

LBH - 170 12.5 17.0 4

LBH - 200 15.0 20.0 5
LBH - 210 15.5 21.0 5

LBH - 250 18.5 25.0 6
LBH - 260 19.0 26.0 6

LBH - 300 22.5 30.0 7

LBH - 310 23.0 31.0 7
LBH - 320 23.5 32.0 7
