INSERT TIP 5

▶ 볼 커터 / Ball Cutter Insert CUTTER SERIES

- 적용 HOLDER : BMCC-MD(689p) INSERT TYPE → WIDIN

Part No. R 치수(Dimensions)mm Θ˚
RBMX50 25 dt 11˚
12.7 5.56

▶ 헬리칼 커터 인서트 / Helical Cutter Insert

- 적용 HOLDER : BMCC-MD(689p), HMCC-MD(698p) INSERT TYPE → WIDIN

Part No. d 치수(Dimensions)mm Θ˚
tR 14˚
11˚
SPMT090308 9.525 3.8 0.8

SPMT120408 12.7 4.76 0.8

커터 시리즈

- 적용 HOLDER : HMCC-MD(698p) INSERT TYPE → WIDIN

Part No. d 치수(Dimensions)mm R
ZPMT1504... 15.88 d1 t 0.8
12.7 4.76
