INSERT TIP

▶ 코너 래디우스 인서트 / Corner Radius Insert (Indexable Milling)

R
d

CUTTER SERIES

I T

- 적용 HOLDER : SRFH(702p), C-SRFH(702p), M-SRFH(714p) INSERT TYPE → WIDIN

커터 시리즈 Part No. I 치수(Dimensions)mm R
8.5 dT 0.5
LRH100-R0.5 8.5 10.0 2.6 1.0
LRH100-R1.0 8.5 10.0 2.6 2.0
LRH100-R2.0 9.0 10.0 2.6 0.5
LRH110-R0.5 9.0 11.0 2.6 1.0
LRH110-R1.0 9.0 11.0 2.6 2.0
LRH110-R2.0 10.0 11.0 2.6 0.5
LRH120-R0.5 10.0 12.0 3 1.0
LRH120-R1.0 10.0 12.0 3 2.0
LRH120-R2.0 10.5 12.0 3 0.5
LRH130-R0.5 10.5 13.0 3 1.0
LRH130-R1.0 10.5 13.0 3 2.0
LRH130-R2.0 12.0 13.0 3 0.5
LRH160-R0.5 12.0 16.0 4 1.0
LRH160-R1.0 12.0 16.0 4 2.0
LRH160-R2.0 12.5 16.0 4 0.5
LRH170-R0.5 12.5 17.0 4 1.0
LRH170-R1.0 12.5 17.0 4 2.0
LRH170-R2.0 15.0 17.0 4 0.5
LRH200-R0.5 15.0 20.0 5 1.0
LRH200-R1.0 15.0 20.0 5 2.0
LRH200-R2.0 15.0 20.0 5 0.5
LRH210-R0.5 15.0 21.0 5 1.0
LRH210-R1.0 15.0 21.0 5 2.0
LRH210-R2.0 18.5 21.0 5 0.5
LRH250-R0.5 18.5 25.0 6 1.0
LRH250-R1.0 18.5 25.0 6 2.0
LRH250-R2.0 19.0 25.0 6 0.5
LRH260-R0.5 19.0 26.0 6 1.0
LRH260-R1.0 19.0 26.0 6 2.0
LRH260-R2.0 22.5 26.0 6 0.5
LRH300-R0.5 22.5 30.0 7 1.0
LRH300-R1.0 22.5 30.0 7 2.0
LRH300-R2.0 22.5 30.0 7 0.5
LRH320-R0.5 22.5 32.0 7 1.0
LRH320-R1.0 22.5 32.0 7 2.0
LRH320-R2.0 32.0 7
