Carbide 60°Helix Carbide Reamers
Chucking Reamers
초경 60도 헬릭스 척킹리머
60° Helical Flutes, Straight Shank 직선샹크

CAR Helix TiALN
Angle
Ultrafine
60°

Item no. D ℓL d Remarks Item no. D ℓ L d Remarks

제품코드 외경 날장 전장 샹크 비고 제품코드 외경 날장 전장 샹크 비고

RM06CA-020 2.0 10 46 D RM06CA-120 12.0 36 151 12
RM06CA-025 2.5 RM06CA-125 12.5 36 151 12
RM06CA-030 3.0 10 46 D RM06CA-130 13.0 38 151 12
RM06CA-035 3.5 RM06CA-135 13.5 38 151 14
RM06CA-040 4.0 15 57 D RM06CA-140 14.0 40 160 14
RM06CA-045 4.5 RM06CA-150 15.0 40 162 14 Top Solid
RM06CA-050 5.0 15 57 D RM06CA-160 16.0 42 170 16
RM06CA-055 5.5 RM06CA-170 17.0 42 175 16
RM06CA-060 6.0 15 75 4 RM06CA-180 18.0 45 182 18
RM06CA-065 6.5 RM06CA-190 19.0 45 189 18
RM06CA-070 7.0 18 80 4.5 Solid RM06CA-200 20.0 48 195 20
RM06CA-075 7.5
RM06CA-080 8.0 20 86 5
RM06CA-085 8.5
RM06CA-090 9.0 20 86 5.5
RM06CA-095 9.5
RM06CA-100 10.0 23 93 6
RM06CA-105 10.5
RM06CA-110 11.0 23 93 6
RM06CA-115 11.5
26 107 7

26 107 7

28 117 8

28 117 8

30 125 9

30 125 9 Tolerance (허용공차)
Top Solid D dℓL

32 133 10 m5 h8 ±1 ±1

32 133 10

35 142 10

35 142 12
