2 Flutes G-TAC Coated Coner Radius End Mills for Non-Ferrous Metal

2 G-TAC

Endmills for Aluminum, Aluminum alloy, copper,
copper alloy, CFRP, glass/carbon fiber, nonferrous and
non-metallic materials.
Tetrabond TAC coating provides excellent work surface finish by
high hardness and low friction.
Reinforced edge design for preventing edge chipping.
High precise edge tolerance.

D Size D Tolerance

1 ~ 4 +0 ~ -0.01mm

0.005 0.01 6 ~ 12 -0.005 ~ -0.015mm
R0.1 ~ 0.5 R1
mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
DR of cut Length Length Dia of cut Length Length Dia
2DLC 010 001 040 2DLC 040 005 250 DR L1 L2 L d
2DLC 010 001 060 L1 L2 L d 2DLC 040 005 300
2DLC 010 001 080 2DLC 040 010 120 4 X R0.5 6 25 65 6
2DLC 010 001 100 1 X R0.1 1.5 4 45 4 2DLC 040 010 160 4 X R0.5 6 30 70 6
2DLC 010 002 040 1 X R0.1 1.5 6 45 4 2DLC 040 010 200 4 X R1 6 12 50 6
2DLC 010 002 060 1 X R0.1 1.5 8 45 4 2DLC 040 010 250 4 X R1 6 16 60 6
2DLC 010 002 080 1 X R0.1 1.5 10 45 4 2DLC 040 010 300 4 X R1 6 20 60 6
2DLC 010 002 100 1 X R0.2 1.5 4 45 4 2DLC 060 003 200 4 X R1 6 25 65 6
2DLC 015 001 060 1 X R0.2 1.5 6 45 4 2DLC 060 005 200 4 X R1 6 30 70 6
2DLC 015 001 080 1 X R0.2 1.5 8 45 4 2DLC 060 010 200 6 X R0.3 9 20 60 6
2DLC 015 001 100 1 X R0.2 1.5 10 45 4 2DLC 080 003 250 6 X R0.5 9 20 60 6
2DLC 015 001 120 1.5 X R0.1 2.3 6 45 4 2DLC 080 005 250 6 X R1 9 20 60 6
2DLC 015 002 060 1.5 X R0.1 2.3 8 45 4 2DLC 080 010 250 8 X R0.3 12 25 65 8
2DLC 015 002 080 1.5 X R0.1 2.3 10 45 4 2DLC 100 005 300 8 X R0.5 12 25 65 8
2DLC 015 002 100 1.5 X R0.1 2.3 12 50 4 2DLC 100 010 300 8 X R1 12 25 65 8
2DLC 015 002 120 1.5 X R0.2 2.3 6 45 4 2DLC 120 005 320 10 X R0.5 15 30 70 10
2DLC 020 002 080 1.5 X R0.2 2.3 8 45 4 2DLC 120 010 320 10 X R1 15 30 70 10
2DLC 020 002 100 1.5 X R0.2 2.3 10 45 4 12 X R0.5 18 32 80 12
2DLC 020 002 120 1.5 X R0.2 2.3 12 50 4 12 X R1 18 32 80 12
2DLC 020 002 160 2 X R0.2 3 8 45 4
2DLC 020 005 080 2 X R0.2 3 10 45 4 G-TAC
2DLC 020 005 100 2 X R0.2 3 12 50 4
2DLC 020 005 120 2 X R0.2 3 16 50 4
2DLC 020 005 160 2 X R0.5 3 8 45 4
2DLC 030 002 100 2 X R0.5 3 10 45 4
2DLC 030 002 120 2 X R0.5 3 12 50 4
2DLC 030 002 160 2 X R0.5 3 16 50 4
2DLC 030 002 200 3 X R0.2 4.5 10 50 6
2DLC 030 002 250 3 X R0.2 4.5 12 50 6
2DLC 030 002 300 3 X R0.2 4.5 16 60 6
2DLC 030 003 100 3 X R0.2 4.5 20 60 6
2DLC 030 003 120 3 X R0.2 4.5 25 65 6
2DLC 030 003 160 3 X R0.2 4.5 30 70 6
2DLC 030 003 200 3 X R0.3 4.5 10 50 6
2DLC 030 003 250 3 X R0.3 4.5 12 50 6
2DLC 030 003 300 3 X R0.3 4.5 16 60 6
2DLC 030 005 100 3 X R0.3 4.5 20 60 6
2DLC 030 005 120 3 X R0.3 4.5 25 65 6
2DLC 030 005 160 3 X R0.3 4.5 30 70 6
2DLC 030 005 200 3 X R0.5 4.5 10 50 6
2DLC 030 005 250 3 X R0.5 4.5 12 50 6
2DLC 030 005 300 3 X R0.5 4.5 16 60 6
2DLC 040 002 120 3 X R0.5 4.5 20 60 6
2DLC 040 002 160 3 X R0.5 4.5 25 65 6
2DLC 040 002 200 3 X R0.5 4.5 30 70 6
2DLC 040 005 120 4 X R0.2 6 12 50 6
2DLC 040 005 160 4 X R0.2 6 16 60 6
2DLC 040 005 200 4 X R0.2 6 20 60 6
4 X R0.5 6 12 50 6
4 X R0.5 6 16 60 6
4 X R0.5 6 20 60 6
