3 Flutes 45 Helix Rib End Mills for Aluminum

3 45

Endmills for Aluminum, AL alloy, non-ferrous and
non-metallic materials.

Applied fine WC grade for excellent surface finish.

Applied short flute length for various applications.
Tetrabond TAC coating provides excellent work surface finish by
high hardness and low friction.

Minimize built up edge by double edge and deep pocket design.

0 0.01 D Size D Tolerance
0.8~ 12 0.8 ~ 12 +0 ~ -0.01mm

Shield Edge mm

Order Number Diameter Length Effective Overall Shank
of cut Length Length Dia
Non coated RTAC RTAC Coated D L1 d Non coated Coated
L2 L
FOR ALUMINUM 3ALR 008 016 S04 New 3ALRC 008 016 S04 0.8 1.6 4
3ALR 008 030 S04 New 3ALRC 008 030 S04 0.8 1.6 - 50 4
3ALR 008 040 S04 New 3ALRC 008 040 S04 0.8 1.6 3 50 4
3ALR 008 050 S04 New 3ALRC 008 050 S04 0.8 1.6 4 50 4
3ALR 008 060 S04 New 3ALRC 008 060 S04 0.8 1.6 5 50 4
3ALR 008 080 S04 New 3ALRC 008 080 S04 0.8 1.6 6 50 4
3ALR 008 100 S04 New 3ALRC 008 010 S04 0.8 1.6 8 50 4
3ALR 008 120 S04 New 3ALRC 008 012 S04 0.8 1.6 10 50 4
3ALR 010 020 S06 New 3ALRC 010 020 S06 1 2 12 50 6
3ALR 010 040 S06 New 3ALRC 010 040 S06 1 2 - 60 6
3ALR 010 060 S06 New 3ALRC 010 060 S06 1 2 4 60 6
3ALR 010 080 S06 New 3ALRC 010 080 S06 1 2 6 60 6
3ALR 010 100 S06 New 3ALRC 010 100 S06 1 2 8 60 6
3ALR 010 120 S06 New 3ALRC 010 120 S06 1 2 10 60 6
3ALR 010 140 S06 New 3ALRC 010 140 S06 1 2 12 60 6
New 3ALR 010 160 S06 New 3ALRC 010 160 S06 1 2 14 60 6
3ALR 015 030 S06 New 3ALRC 015 030 S06 1.5 3 16 60 6
3ALR 015 060 S06 New 3ALRC 015 060 S06 1.5 3 - 60 6
3ALR 015 080 S06 New 3ALRC 015 080 S06 1.5 3 6 60 6
3ALR 015 100 S06 New 3ALRC 015 100 S06 1.5 3 8 60 6
3ALR 015 120 S06 New 3ALRC 015 120 S06 1.5 3 10 60 6
3ALR 015 140 S06 New 3ALRC 015 140 S06 1.5 3 12 60 6
3ALR 015 160 S06 New 3ALRC 015 160 S06 1.5 3 14 60 6
New 3ALR 015 180 S06 New 3ALRC 015 180 S06 1.5 3 16 60 6
New 3ALR 015 200 S06 New 3ALRC 015 200 S06 1.5 3 18 60 6
3ALR 020 040 S06 New 3ALRC 020 040 S06 2 4 20 60 6
3ALR 020 080 S06 New 3ALRC 020 080 S06 2 4 - 60 6
3ALR 020 100 S06 New 3ALRC 020 100 S06 2 4 8 60 6
3ALR 020 120 S06 New 3ALRC 020 120 S06 2 4 10 60 6
3ALR 020 140 S06 New 3ALRC 020 140 S06 2 4 12 60 6
3ALR 020 160 S06 New 3ALRC 020 160 S06 2 4 14 60 6
3ALR 020 200 S06 New 3ALRC 020 200 S06 2 4 16 60 6
New 3ALR 020 220 S06 New 3ALRC 020 220 S06 2 4 20 60 6
New 3ALR 020 250 S06 New 3ALRC 020 250 S06 2 4 22 60 6
3ALR 025 050 S06 New 3ALRC 025 050 S06 2.5 5 25 65 6
3ALR 025 100 S06 New 3ALRC 025 100 S06 2.5 5 - 60 6
3ALR 025 150 S06 New 3ALRC 025 150 S06 2.5 5 10 60 6
3ALR 025 200 S06 New 3ALRC 025 200 S06 2.5 5 15 60 6
3ALR 025 250 S06 New 3ALRC 025 250 S06 2.5 5 20 60 6
New 3ALR 025 300 S06 New 3ALRC 025 300 S06 2.5 5 25 60 6
3ALR 030 060 S06 New 3ALRC 030 060 S06 3 6 30 70 6
3ALR 030 100 S06 New 3ALRC 030 100 S06 3 6 - 60 6
3ALR 030 150 S06 New 3ALRC 030 150 S06 3 6 10 60 6
3ALR 030 200 S06 New 3ALRC 030 200 S06 3 6 15 60 6
3ALR 030 250 S06 New 3ALRC 030 250 S06 3 6 20 70 6
3ALR 030 300 S06 New 3ALRC 030 300 S06 3 6 25 70 6
New 3ALR 030 350 S06 New 3ALRC 030 350 S06 3 6 30 80 6
New 3ALR 030 400 S06 New 3ALRC 030 400 S06 3 6 35 80 6
40 90
