HSD-V 2×D

DRILLING

● Shank ISO9766, Parallel with clamping flat

Code No. 치수 Dimension(mm) 인서트 부품 Component
HSD-V20520D S25 Insert Screw T-Driver
HSD-V21020D S25 D L1 L Ds Ls WCMX040204 TSB-25055
HSD-V21520D S25 56 WCMX050308
HSD-V22020D S25 20.5 44 125 25 60 WCMX06T308 TXL-8
HSD-V22520D S25 21.0 45 126 32 TSB-30070
HSD-V23020D S25 21.5 46 127 40 70 WCMX080408
HSD-V23520D S25 22.0 47 128 TSB-35090
HSD-V24020D S25 22.5 48 129
HSD-V24520D S25 23.0 49 130 TXL-15
HSD-V25020D S25 23.5 50 131 TSB-40110
HSD-V25520D S32 24.0 51 132
HSD-V26020D S32 24.5 52 133
HSD-V26520D S32 25.0 53 134
HSD-V27020D S32 25.5 54 144
HSD-V27520D S32 26.0 55 145
HSD-V28020D S32 26.5 56 146
HSD-V28520D S32 27.0 57 147
HSD-V29020D S32 27.5 58 148
HSD-V29520D S32 28.0 59 149
HSD-V30020D S32 28.5 60 150
HSD-V31020D S32 29.0 61 151
HSD-V32020D S32 29.5 62 152
HSD-V33020D S32 30.0 63 153
HSD-V34020D S32 31.0 65 155
HSD-V35020D S32 32.0 67 157
HSD-V36020D S32 33.0 69 159
HSD-V37020D S32 34.0 71 161
HSD-V38020D S32 35.0 73 163
HSD-V39020D S32 36.0 75 165
HSD-V40020D S32 37.0 77 167
HSD-V41020D S32 38.0 79 169
HSD-V42020D S40 39.0 81 171
HSD-V43020D S40 40.0 83 173
HSD-V44020D S40 41.0 85 175
HSD-V45020D S40 42.0 87 192
HSD-V46020D S40 43.0 89 194
HSD-V47020D S40 44.0 91 196
HSD-V48020D S40 45.0 93 198
HSD-V49020D S40 46.0 95 200
HSD-V50020D S40 47.0 97 202
HSD-V51020D S40 48.0 99 204
HSD-V52020D S40 49.0 101 206
HSD-V53020D S40 50.0 103 208
HSD-V54020D S40 51.0 105 210
HSD-V55020D S40 52.0 107 212
HSD-V56020D S40 53.0 109 214
HSD-V57020D S40 54.0 111 216
HSD-V58020D S40 55.0 113 218
56.0 115 220
57.0 117 222
58.0 119 224

※ 가공경 ø40 이상을 범용선반에서 가공할 경우 센터붙이 타입 드릴(VLT, FXD, VMD) 사용을 권장합니다.
HSD-V드릴과 체결되는 툴 홀더는 '사이드락 아버'(78페이지~90페이지)입니다.

※ If you are working on the lathe, diameter ø40 or higher, we recommend using the VLT, FXD, VMD
The tool holder that locks with HSD-V is Side Lock Arbor.(P.78~P.90)
