ENDMILL CUTTER 5

▶ ASRL-Pico CUTTER SERIES

- STRIGHT SHANK TYPE INSERT TYPE → HITACHI, WIDIN

Part No. 치수(Dimensions)mm I 2
Dd L 120
ASRL-1616160-2F 16 16 160 130 2
ASRL-1716160-2F 17 16 160 170
ASRL-1716200-2F 17 16 200 160 2
ASRL-2020200-3F 20 20 200 170
ASRL-2120200-3F 21 20 200 150 3
ASRL-2525200-4F 25 25 200 200
ASRL-2525250-4F 25 25 250 160 3
ASRL-2625200-4F 26 25 200 210
ASRL-2625250-4F 26 25 250 135 4
ASRL-3232200-5F 32 32 200 185
ASRL-3232250-5F 32 32 250 160 4 EPNW0603TN-8 ST2553-55 M2.5 TX-8
ASRL-3332200-5F 33 32 200 210
ASRL-3332250-5F 32 32 250 4

4

5

5

5

5

D Kd

L

- BORE MOUNTED TYPE INSERT TYPE → KORLOY, WIDIN 커터 시리즈

Part No. 치수(Dimensions)mm K
Dd L 10.4
10.4
ASRL-D42x16x6F 42 16 40 10.4 6
12.7
ASRL-D50x22x7F 50 22 50 12.7 7
12.7
ASRL-D52x22x7F 52 22 50 7 EPNW0603TN-8 ST2553-55 TX-8
8 M2.5
ASRL-D63x27x8F 63 27 50

ASRL-D66x27x8F 66 27 50 8

ASRL-D80x27x10F 80 27 65 10
