SHRINK FIT CHUCK -Designed 3˚ slope

DIN69893 HSK/A-SHR Ød1 D1 D2 L1 ㎜
17.1 3 9 9
CODE NO. 18.1 4 10 12 L
SHR3-80 19.1 5 11 15 80
SHR4-80 20.1 6 12 25 80
SHR5-80 20.1 6 12 25 80
SHR6-80 22.1 8 14 25 80
SHR6-120 22.1 8 14 25 120
SHR8-80 24.1 10 16 32 80
SHR8-120 24.1 10 16 32 120
SHR10-85 26.1 12 18 38 85
SHR10-120 26.1 12 18 38 120
SHR12-90 28.1 14 20 38 90
SHR12-120 28.1 14 20 38 120
30.1 16 22 40 90
HSK63A SHR14-90 30.1 16 22 38 120
SHR14-120 32.1 18 24 42 95
SHR16-95 32.1 18 24 42 120
SHR16-120 34.1 20 26 44 95
SHR18-95 34.1 20 26 44 120
SHR18-120 39.1 25 31 50 100
SHR20-100 39.1 25 31 50 120
SHR20-120 46.1 32 38 50 115
SHR25-115 46.1 32 38 50 130
SHR25-130 120
SHR32-120 130
SHR32-130

Taper : AT3 | T.I.R ≥3 : /2.5xD | Bal/rpm : G2.5/20000 | Coolant : AD | For : Solid Carbide

툴홀더 시스템 ㎜

구분 절삭공구SHANKØ Ø3-6 Ø6.1-10 Ø10.1-14 Ø14.1-18 Ø18.1-24 Ø24.1-30 Ø30.1-40

h6 0-8um 0-9um 0-11um 0-11um 0-13um 0-13um 0-16um
