SHRINK FIT CHUCK -Designed 3˚ slope TOOL HOLDER7
TOOL HOLDER SYSTEM
DIN69893 HSK/E-SHR ㎜
CODE NO. Ød1 D1 D2 L1 L
19 3 9 9 60
SHR3-60 19 3 9 9 120
20 4 10 12 60
SHR3-120 20 4 10 12 120
21 5 11 15 60
SHR4-60 21 5 11 15 120
22 6 12 25 80
SHR4-120 22 6 12 25 120
24 8 14 25 80
SHR5-60 24 8 14 25 120
26 10 16 32 80
SHR5-120 26 10 16 32 120
28 12 18 38 90
HSK40E SHR6-80 28 12 18 38 120
SHR6-120
SHR8-80
SHR8-120
SHR10-80
SHR10-120
SHR12-90
SHR12-120
Taper : AT3 | T.I.R ≥3 : /2.5xD | Bal/rpm : G2.5/20000 | Coolant : AD | For : Solid Carbide
구분 SHANKØ Ø3-6 Ø6.1-10 Ø10.1-14 Ø14.1-18 Ø18.1-24 Ø24.1-30 Ø30.1-40
h6 0-8um 0-9um 0-11um 0-11um 0-13um 0-13um 0-16um
