TOOL HTOOOLLDHEOLRDER SYSTEM7
SHRINK FIT CHUCK -Designed 3˚ slope

DIN69893 HSK/A-SHR ㎜

CODE NO. Ød1 D1 D2 L1 L
19 3 9 9 60
SHR3-60 19 3 9 9 120
20 4 10 12 60
SHR3-120 20 4 10 12 120
21 5 11 15 60
SHR4-60 21 5 11 15 120
22 6 12 25 80
SHR4-120 22 6 12 25 120
24 8 14 25 80
SHR5-60 24 8 14 25 120
26 10 16 32 80
SHR5-120 26 10 16 32 120
28 12 18 38 90
HSK40A SHR6-80 28 12 18 38 120
SHR6-120

SHR8-80

SHR8-120

SHR10-80

SHR10-120

SHR12-90

SHR12-120

Taper : AT3 | T.I.R ≥3 : /2.5xD | Bal/rpm : G2.5/20000 | Coolant : AD | For : Solid Carbide
