Carbide End Mills 초경 2날
알루미늄용 엔드밀
Solid Carbide
End Mills for Al, Cu

2 Flutes

CAR 2FUltrafine Helix
Angle

45°

Item no. D ℓ L d Tolerance (허용공차)

제품코드 규격 날장 전장 샹크 DdL

EM07CA-020 2.0 8 45 6 h10 h6 ±1

EM07CA-025 2.5 8 45 6

EM07CA-030 3.0 12 50 6

EM07CA-040 4.0 12 50 6

EM07CA-050 5.0 16 57 6

EM07CA-060 6.0 16 57 6

EM07CA-070 7.0 20 63 8

EM07CA-080 8.0 20 63 8

EM07CA-090 9.0 25 70 10

EM07CA-100 10.0 25 70 10

EM07CA-110 11.0 30 80 12

EM07CA-120 12.0 32 80 12

EM07CA-140 14.0 35 85 14

EM07CA-160 16.0 40 90 16

114 2014/15 DYC TOOLS LIST
