P. 117

Solid Carbide                                            Carbide End Mills
End Mills for Al, Cu
                                                                초경 3날
3 Flutes                                             알루미늄용 엔드밀

CAR 3FUltrafine  Helix
                 Angle

                   45°

Item no.         DℓL           d  Item no.      DℓL          d

제품코드             규격 날장 전장 샹크      제품코드          규격 날장 전장 샹크

EM08CA-03001            12 50  6  EM08CA-06006  6.0  40 80   6
                               6                             6
EM08CA-03002            15 50  6  EM08CA-06007       45 80
                               6
EM08CA-03003 3.0 20 62         6  EM08CA-06501 6.5 18 57     8
                               6
EM08CA-03004            25 62  6  EM08CA-07001       20 63   8
                               6
EM08CA-03005            30 70  6  EM08CA-07002 7.0 35 80     8
                               6
EM08CA-03501 3.5 12 50         6  EM08CA-07003       40 80   8
                               6
EM08CA-04001            14 50  6  EM08CA-08001       20 63   8
                               6
EM08CA-04002            20 62  6  EM08CA-08002       25 63   8
                               6
EM08CA-04003 4.0 25 62         6  EM08CA-08003       30 70   8
                               6
EM08CA-04004            30 70  6  EM08CA-08004 8.0 35 80     8
                               6
EM08CA-04005            35 70  6  EM08CA-08005       40 90   8
                               6
EM08CA-04501 4.5 14 50         6  EM08CA-08006       50 100  8
                               6
EM08CA-05001            16 57     EM08CA-08007       60 110  8

EM08CA-05002            20 57     EM08CA-09001       25 70 10

EM08CA-05003     5.0    25 62     EM08CA-09002  9.0  35 80 10

EM08CA-05004            30 70     EM08CA-09003       45 90 10

EM08CA-05005            35 70     EM08CA-09004       60 105 10

EM08CA-05006            40 75     EM08CA-10001       25 70 10

EM08CA-05501 5.5 16 57            EM08CA-10002       30 80 10

EM08CA-06001            16 57     EM08CA-10003       35 80 10

EM08CA-06002            20 57     EM08CA-10004 10.0  40  90  10

EM08CA-06003 6.0 25 62            EM08CA-10005       45 100 10

EM08CA-06004            30 70     EM08CA-10006       50 110 10

EM08CA-06005            35 80     EM08CA-10007       60 110 10

                                                     2014/15 DYC TOOLS LIST 115
