Solid Carbide Wave Carbide End Mills
Roughing End Mills
초경 3날
3 Flutes 알루미늄용 웨이브

라핑 엔드밀

CAR 3FUltrafine Helix
Angle

45°

Item no. D ℓ L C d Tolerance (허용공차)

제품코드 규격 날장 전장 코너 샹크 Dd L

EM11CA-060 6.0 18 63 0.3 6 js14 h6 ±1
EM11CA-070 7.0 23 63 0.3 8
EM11CA-080 8.0 23 63 0.3 8
EM11CA-090 9.0 30 80 0.3 10
EM11CA-100 10.0 30 80 0.3 10
EM11CA-110 11.0 32 80 0.5 12
EM11CA-120 12.0 32 80 0.5 12
EM11CA-140 14.0 32 80 0.5 14
EM11CA-160 16.0 48 105 0.5 16
EM11CA-180 18.0 48 105 0.5 18
EM11CA-200 20.0 50 105 0.5 20
EM11CA-250 25.0 50 105 0.5 25

2014/15 DYC TOOLS LIST 119
