CBN, 2 Flutes High Speed Straight Rib Corner Radius End Mills FOR CBN

2 CBN

PCBN ENDMILL for precise finishing( 5 ) of hardened

steel (HRc50~72)

Long tool life by high content PCBN.

Straight type Design for Minimizing edge chipping.

Excellent surface finish.

Various flute length for optimum performance.

Recommend high speed(20,000~50,000RPM) with oil-mist.

C.B.N (Cubic Boron Nitride)

D Size D Tolerance

0.005 0.4 ~ 6 +0 ~ -0.01mm
R0.02 ~ 1
mm

Order Number Diameter Length Effective Overall Shank Order Number Diameter Length Effective Overall Shank
DR of cut Length Length Dia of cut Length Length Dia
2SCCBN 004 0002 015 2SCCBN 030 002 060 DR L1 L2 L d
2SCCBN 004 0005 015 L1 L2 L d 2SCCBN 030 002 100
2SCCBN 004 001 015 2SCCBN 030 003 060 3 X R0.2 1.2 6 66 6
2SCCBN 005 0005 015 0.4 X R0.02 0.3 1.5 48 4 2SCCBN 030 003 100 3 X R0.2 1.2 10 66 6
2SCCBN 005 001 015 0.4 X R0.05 0.3 1.5 48 4 2SCCBN 030 005 060 3 X R0.3 1.2 6 66 6
2SCCBN 006 0005 020 0.4 X R0.1 0.3 1.5 48 4 2SCCBN 030 005 100 3 X R0.3 1.2 10 66 6
2SCCBN 006 001 020 0.5 X R0.05 0.4 1.5 48 4 2SCCBN 030 005 160 3 X R0.5 1.2 6 66 6
2SCCBN 008 001 020 0.5 X R0.1 0.4 1.5 48 4 2SCCBN 030 010 060 3 X R0.5 1.2 10 66 6
2SCCBN 008 002 020 0.6 X R0.05 0.5 2 48 4 2SCCBN 030 010 100 3 X R0.5 1.2 16 66 6
2SCCBN 010 0002 025 0.6 X R0.1 0.5 2 48 4 2SCCBN 030 010 160 3 X R1 1.2 6 66 6
2SCCBN 010 0002 040 0.8 X R0.1 0.6 2 48 4 2SCCBN 040 001 060 3 X R1 1.2 10 66 6
2SCCBN 010 0005 025 0.8 X R0.2 0.6 2 48 4 2SCCBN 040 001 100 3 X R1 1.2 16 66 6
2SCCBN 010 0005 040 1 X R0.02 0.7 2.5 48 4 2SCCBN 040 001 160 4 X R0.1 1.5 6 66 6
2SCCBN 010 001 025 1 X R0.02 0.7 4 48 4 2SCCBN 040 002 060 4 X R0.1 1.5 10 66 6
2SCCBN 010 001 040 1 X R0.05 0.7 2.5 48 4 2SCCBN 040 002 100 4 X R0.1 1.5 16 66 6
2SCCBN 010 002 025 1 X R0.05 0.7 4 48 4 2SCCBN 040 002 160 4 X R0.2 1.5 6 66 6
2SCCBN 010 002 040 1 X R0.1 0.7 2.5 48 4 2SCCBN 040 003 060 4 X R0.2 1.5 10 66 6
2SCCBN 010 003 025 1 X R0.1 0.7 4 48 4 2SCCBN 040 003 100 4 X R0.2 1.5 16 66 6
2SCCBN 010 003 040 1 X R0.2 0.7 2.5 48 4 2SCCBN 040 003 160 4 X R0.3 1.5 6 66 6
2SCCBN 015 0002 030 1 X R0.2 0.7 4 48 4 2SCCBN 040 005 060 4 X R0.3 1.5 10 66 6
2SCCBN 015 0002 040 1 X R0.3 0.7 2.5 48 4 2SCCBN 040 005 100 4 X R0.3 1.5 16 66 6
2SCCBN 015 0005 030 1 X R0.3 0.7 4 48 4 2SCCBN 040 005 160 4 X R0.5 1.5 6 66 6
2SCCBN 015 0005 040 1.5 X R0.02 0.8 3 48 4 2SCCBN 040 010 060 4 X R0.5 1.5 10 66 6
2SCCBN 015 001 030 1.5 X R0.02 0.8 4 48 4 2SCCBN 040 010 100 4 X R0.5 1.5 16 66 6
2SCCBN 015 001 040 1.5 X R0.05 0.8 3 48 4 2SCCBN 040 010 160 4 X R1 1.5 6 66 6
2SCCBN 015 002 030 1.5 X R0.05 0.8 4 48 4 2SCCBN 060 003 030 4 X R1 1.5 10 66 6
2SCCBN 015 002 040 1.5 X R0.1 0.8 3 48 4 2SCCBN 060 003 150 4 X R1 1.5 16 66 6
2SCCBN 015 003 030 1.5 X R0.1 0.8 4 48 4 2SCCBN 060 005 030 6 X R0.3 3 - 83 6
2SCCBN 015 003 040 1.5 X R0.2 0.8 3 48 4 2SCCBN 060 005 150 6 X R0.3 3 15 83 6
2SCCBN 020 0002 030 1.5 X R0.2 0.8 4 48 4 2SCCBN 060 010 030 6 X R0.5 3 - 83 6
2SCCBN 020 0002 060 1.5 X R0.3 0.8 3 48 4 2SCCBN 060 010 150 6 X R0.5 3 15 83 6
2SCCBN 020 0005 030 1.5 X R0.3 0.8 4 48 4 6 X R1 3 - 83 6
2SCCBN 020 0005 060 2 X R0.02 0.9 3 50 4 6 X R1 3 15 83 6
2SCCBN 020 001 030 2 X R0.02 0.9 6 50 4
2SCCBN 020 001 060 2 X R0.05 0.9 3 50 4
2SCCBN 020 002 030 2 X R0.05 0.9 6 50 4
2SCCBN 020 002 060 2 X R0.1 0.9 3 50 4
2SCCBN 020 003 030 2 X R0.1 0.9 6 50 4
2SCCBN 020 003 060 2 X R0.2 0.9 3 50 4
2SCCBN 020 005 030 2 X R0.2 0.9 6 50 4
2SCCBN 020 005 060 2 X R0.3 0.9 3 50 4
2SCCBN 025 001 060 2 X R0.3 0.9 6 50 4
2SCCBN 025 002 060 2 X R0.5 0.9 3 50 4
2SCCBN 025 003 060 2 X R0.5 0.9 6 50 4
2SCCBN 030 001 060 2.5 X R0.1 1.2 6 66 6
2SCCBN 030 001 100 2.5 X R0.2 1.2 6 66 6
2.5 X R0.3 1.2 6 66 6
3 X R0.1 1.2 6 66 6
3 X R0.1 1.2 10 66 6
