LC-NKㆍNKD TYPE 8

▶ NKBC-TYPE LIVE CENTER

※ SHAFT 확장(바이트 간섭 최소화)
※ 초경타입

Model Order Morse Dimension Weight R.P.M Run
Number Taper B L1 L2 L3 L4
GL A L5 C L MAX. MAX. Out

LC-3NKBC 021103 NO.3 23.825 52 22 48 42 5 95 80 10 175 1900 5000 0.003

LC-4NKBC 021104 NO.4 31.267 66 32 53 57 6.5 116.5 101.5 14 218 2700 3800 0.003

LC-5NKBC 021105 NO.5 44.399 80 40 65.5 57 6.5 129 129.5 18 258.5 3200 3400 0.005

LC-6NKBC 021106 NO.6 63.348 132 65 78 100 8 186 182 25 368 10000 1800 0.005

▶ NKN-TYPE

※ 너트 타입

Model Order Morse Dimension Weight R.P.M Run
Number Taper B L1 L2 L3 L4 L5 N Out
LC-3NKN GL A L MAX. MAX.
LC-4NKN 020013 NO.3 0.003
LC-5NKN 020014 NO.4 23.825 52 22 29 42 5 76 80 70 156 1900 5000 0.003
LC-6NKN 020015 NO.5 31.267 66 3800 0.005
LC-7NKN 020016 NO.6 44.399 80 32 37 57 6.5 100.5 101.5 85 202 2700 3400 0.005
020017 NO.7 63.348 132 1800 0.005
83.058 168 40 45.5 57 6.5 109 129.5 98 238.5 3200 1200

65 65 100 8 173 182 165 355 10000

72 84 128 10 222 250 210 427 17200

▶ NKBN-TYPE

※ SHAFT 확장(바이트 간섭 최소화)
※ 너트 타입

Model Order Morse GL A B Dimension Weight R.P.M Run
Number Taper b L1 L2 L3 L4 L5 N L MAX. MAX. Out
LC-3NKBN 23.825 52 22
LC-4NKBN 021013 NO.3 31.267 66 32 10 48 42 5 95 80 70 175 1900 5000 0.003 라이브센터 시리즈
LC-5NKBN 021014 NO.4 44.399 80 40
LC-6NKBN 021015 NO.5 63.348 132 65 14 53 57 6.5 116.5 101.5 85 218 2700 3800 0.003
021016 NO.6
18 65.5 57 6.5 129 129.5 98 258.5 3200 3400 0.005

25 78 100 8 186 182 165 368 10000 1800 0.005
